| ब्रांड नाम: | BOE |
| मॉडल संख्या: | NS080WUM-NX1 |
| एमओक्यू: | 10PCS |
| कीमत: | negotiable |
| भुगतान की शर्तें: | टी/टी, डब्ल्यू, वेस्टर्न यूनियन, मनीग्राम |
| आपूर्ति की योग्यता: | प्रति सप्ताह 3000pcs |
| Parameter | Specification |
|---|---|
| Brand | BOE |
| Model P/N | NS080WUM-NX1 |
| Diagonal Size | 8.0" |
| Panel Type | LTPS TFT-LCD, LCM |
| Resolution | 1920(RGB)*1200, WUXGA (283 PPI) |
| Active Area | 172.244(W)*107.64(H) mm |
| Outline Size | 176.324(W)*115.79(H)*3.6(D) mm |
| Brightness | 500 cd/m² (Typ.) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Display Colors | 16.7M (100% sRGB) |
| Refresh Rate | 120Hz |
| Contrast Ratio | 1200:1 (Typ.) |
| Response Time | 17ms (Typ.)(Tr+Td), 25ms (Typ.)(G to G) |
| Display Mode | ADS, Normally Black, Transmissive |
| Surface Treatment | Hard coating (3H) |
| Lamp Type | 10S4P WLED, 15K hours, With LED Driver |
| Touch Screen | In-Cell Touch, I²C |
| Signal Interface | eDP (2 Lanes), eDP1.4, HBR1 (2.7G/lane), 40 pins Connector |
| Input Voltage | 3.3V (Typ.) |
| Operating Temperature | 0 ~ 50 °C |
| Storage Temperature | -20 ~ 60 °C |
